Brand

Plustek
Model

SmartOffice SN8016U
Image Sensor

CIS x 2
Light Source

LED
Optical Resolution

600 dpi
Hardware Resolution

600 x 600 dpi
Scan Modes (Bit Depth)

Color: Input 48-bit, Output 24-bit
Grayscale: Input 16-bit, Output 8-bit
Black & White: 1-bit
ADF Capacity

1. 100 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs), Max. thickness under 10 mm (0.4”)
2. 50 sheets (A3, 70 g/㎡ or 18 Lbs)
3. 20 sheets (Business Cards)
4. Plastic Card (Landscape Loading), Max. thickness under 1.2 mm, embossed cards can be scanned.

Note: Maximum ADF capacity varies, depending upon paper weight.
Scan Speed (ADF)

80 ppm/ 160 ipm (Grayscale/ B&W mode, 300 dpi, A4 Landscape)
55 ppm/ 110 ipm (Color mode, 200 dpi, A4 Landscape)
36 ppm/ 72 ipm (Color mode, 300 dpi, A4 Landscape)
Note: Results may vary depending upon your scanning application, computer processor and system memory.
Scanning Area (W x L)

Max: 297 x 5080 mm
Min: 13.2 x 13.2 mm, [us] Max: 11.69” x 200”
Min: 0.52” x 0.52”
Acceptable Paper Sizes (W x L)

Max: 305 x 5080 mm
Min: 50.8 x 63.5 mm, [us] Max: 12” x 200”
Min: 2” x 2.5”
Acceptable Paper Weight (Thickness)

40 to 220 g/㎡ (10 to 58 Lbs)
Multi-feed Detection

With ultrasonic technology
Daily Duty Scan ( Sheets )

8000
Separate Roller Lifetime (Scans)

300,000
Pad Lifetime (Scans)

100,000
Action Button

4 Buttons: Power, Up, Down, Cancel, Scan
9 function keys are all customizable.
Power Supply

24 Vdc/ 2.7 A
Connectivity

1x USB 2.0 Gen 1 Type B
1x RJ45 – LAN
Net Weight

6.57 kg, [us] 14.48 lbs
Dimensions s (W x D x H)

436 x 262 x 266 mm, [us] 17.16" x 10.31" x 10.47"
Protocol

TWAIN Compliant
Operating System

Windows XP / Vista / 7 / 8 / 10 / 11
Linux compatibility is only available for system integrators.
Hardware Requirements

Windows Recommended:
3.2 GHz Intel® Core™ i7 Processor with 4 CPU Cores or higher
4 GB RAM minimum (Recommended: 8 GB or more)
6 GB of hard-disk space for program installation
Display dimensions of 1024×768 or greater
Bundled Software

Plustek DocAction
Plustek DocTWAIN
Built-in OCR

Plustek OCR
(Powered by ABBYY® FineReader®)
