Brand

Plustek
Model

S60
Image Sensor

CIS x 2
Light Source

LED
Optical Resolution

600 dpi
Hardware Resolution

600 x 600 dpi
Scan Modes (Bit Depth)

Color: Input 48-bit, Output 24-bit
Grayscale: Input 16-bit, Output 8-bit
Black & White: 1-bit
ADF Capacity

1. 100 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs), Max. thickness under 10 mm (0.4”)
2. 50 sheets (A3, 70 g/㎡ or 18 Lbs)
3. 20 sheets (Business Cards)
4. Plastic Card (Landscape Loading), Max. thickness under 1.2 mm, embossed cards can be scanned.

Note: Maximum ADF capacity varies, depending upon paper weight.
Scan Speed (ADF)

64 ppm/ 128 ipm (Color mode, 300 dpi, A4 Landscape)
64 ppm/ 128 ipm (Color mode, 200 dpi, A4 Landscape)
48 ppm/ 96 ipm (Color mode, 300 dpi, A4 Portrait)
48 ppm/ 96 ipm (Color mode, 200 dpi, A4 Portrait)
36 ppm/ 72 ipm (Color mode, 300 dpi, A3)
36 ppm/ 72 ipm (Color mode, 200 dpi, A3)
Note: Results may vary depending upon your scanning application, computer processor and system memory.
Scanning Area (W x L)

Max: 304.8 x 431.8 mm
Min: 13.2 x 13.2 mm
Long Paper: 304.8 x 5080 mm
Acceptable Paper Sizes (W x L)

Max: 304.8 x 431.8 mm
Min: 50.8 x 63.5 mm
Acceptable Paper Weight (Thickness)

40 to 220 g/㎡ (10 to 58 Lbs)
Multi-feed Detection

With ultrasonic technology
Daily Duty Scan ( Sheets )

18000
Separate Roller Lifetime (Scans)

300,000
Pick Roller Lifetime (Scans)

300,000
Friction Roller Lifetime (Scans)

100,000
Action Button

5 Buttons: Power, Up, Down, Cancel, Scan
9 function keys are all customizable.
Power Supply

24 Vdc/ 1.25 A
Connectivity

1x USB 3.2 Gen 1 Type B
Net Weight

6.8 kg
Dimensions s (W x D x H)

405 x 272 x 297 mm
Protocol

TWAIN Compliant
Operating System

Windows 7 / 8 / 10 / 11
