Brand

Viewsonic

Model

IFP8650-5

Screen Size

86"

Display Viewing Area (HxV)

1913.0(H) x 1084.0 (V)

Panel Type

TFT LCD Module with DLED Backlight. IPS

Display Resolution

UHD 3840×2160

Resolution Type

UHD

Display Color

1.07B colors (10bit)

Aspect Ratio

16:9

Brightness

400 nits (typ.), 450 nits (max.)

Contrast Ratio

1200:1 (typ.) 5000:1 (DCR)

Response Time

8ms

Viewing Angles

H = 178, V = 178 typ.

Backlight Life (Hours)

50,000 hours (Min)

Surface Treatment

Hardness: 7H, Anti-glare coating

Bezel

Slim

Curvature

Flat

Refresh Rate (Hz)

60

Processor

ARM Cortex-A73*4 + Cortex-A53*4

RAM

4GB

Storage

32GB

Touch

Type/ Tech: Ultra Fine Touch Techology (IR Recognition)
Touch Resolution: 32768 ×32768
Touch Point: Windows: 40 points of touch, Android : 20 points of touch

Input

HDMI: 2.0 x 3 (3840×2160 @60Hz, HDCP2.2, HDMI1 with CEC/ARC)
RS232: x1
OPS: x1
WiFi: x 1 module slot

Output

HDMI: x1 (4K@60Hz)
Audio: x1 (Earphone out)
SPDIF: x1 (optical)

LAN

2x RJ45

USB

2x Type-A 2.0
2x Type-A 3.0
2x Type-B for touch
1x Type C (DP 1.2, USB2.0, PD65W, Ethernet 100M)

Audio

2x 15W
1x 16W subwoofers

Top Camera Plate

Yes

Embedded OS

Android 11

Bundle Software

Basic Annotation Software: myViewBoard
Pro Annotation Software: myViewBoard for Windows (Embedded in Windows Slot-in PC)
Wireless Presentation: vCast/myViewBoard Display App

Special Features

All-in-one USB port: “SmartPort™ USB” to all channels.
Simple LAN sharing between IFP and slot-in device: Yes
Light Sensor: Yes

Power

Voltage: 100-240VAC +/- 10% Wide Range
Consumption: 158W(typ.), 0.5W (off)

Wall Mount

800 mm x 600 mm

Product Dimensions

Physical (inch / mm): 77.1 x 45.7 x 3.5 in / 1958 x 1160 x 90 mm
Packaging (inch / mm): 83.6 x 53.0 x 11.0 in / 2123 x 1345 x 280 mm

Weight

Net (lb / kg): 150.8lb/68.4kg
Gross (lb / kg): 200lb/90.7kg

Color

Black

Warranty

1 Year
