Compact and with versatile network features.
The SmartOffice PN30U is the network-compatible* further development of the successful model PS30D. The compact scanner not only has an improved retraction mechanism with reversible wheels and an ultrasonic sensor, but also has improved image processing. Key feature of the new scanner is its extensive possibilities in network environments. Once integrated into the local Windows network, the device can be accessed from any workplace. Furthermore, functions such as scanning in FTP or network folders are available.
Ideal for businesses with high digitisation needs that store their documents on networks.
Scan at the touch of a button.
Already included is the Plustek DocAction and MacAction software. In combination with this and the two one-touch function keys, up to 9 different scan profiles can be retrieved, or configured user-specifically. In addition to searchable PDF files, Microsoft Office file formats and image formats such as JPG and TIFF can be generated. In addition, it can be defined whether to store the file in a local or network folder, to the printer, via email, via FTP, or to a cloud folder.
Product features:
• Fast scanning with 30 ppm/60 ipm in colour, greyscale and black and white
• ADF template capacity up to 50 sheets and 4000 pages daily volume.
• Scan documents up to 5080mm in length
• Built-in ultrasonic sensor to prevent multiple insertion
• Improved transport mechanism for optimal template transport.
• Windows network sharing for all Windows users on the network*
• Improved image processing for perfect results
• TWAIN compatible.
* Note: Network function only for Windows networks
Brand | Plustek |
---|---|
Model | SmartOffice PN30U |
Type | Sheet-Feed ADF Scanner |
Image Sensor | CIS x 2 (Duplex Scanner) |
Light Source | LED |
Optical Resolution | 600 dpi |
Hardware Resolution | 600 x 600 dpi |
Scan Modes (Bit Depth) | Color: Input 48-bit, Output 24-bit |
ADF Capacity | 1. 50 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs), Max. thickness under 5mm (0.2"). |
Scan Speed | 30 ppm/ 60 ipm (Grayscale mode, 200 & 300 dpi, A4 Portrait) |
Scanning Area | Max: 216 x 5080 mm (8.5” x 200”) |
Acceptable Paper Sizes (W x L) | Max: 220 x 5080 mm (8.66” x 200”) |
Acceptable Paper Weight (Thickness) | 50 to 105 g/㎡ (14 to 28 Lbs) |
Daily Duty Scan ( Sheets ) | 4000 |
Buttons | 3 Buttons: Up, Down, Scan. |
Power Supply | AC adapter: 24 Vdc/ 0.75 A |
Connectivity | USB 2.0 |
Weight | 1.66 Kgs (3.66 Lbs) |
Dimensions s (W x D x H) | 263 x 128 x 148 mm (10.36" x 5.02" x 5.83") |
Protocol | TWAIN Compliant |
System Requirements | Windows XP / Vista / 7 / 8 / 10 / 11 |
Hardware Requirements | Windows Recommended: 2.8 GHz Intel Core i5 Processor with 4 CPU Cores or higher |
Built-in OCR | Plustek OCR (For Windows) |
Warranty | 1 Year |
