Brand

Asrock
Model

B760M-H2/M.2
Chipset

Intel B760
Socket

LGA1700
CPU

Supports 14th, 13th & 12th Gen Processors (LGA1700)
Memory Channel

Dual Channel DDR5
DIMM Slots

2 x DDR5 DIMM Slots
Max Memory

Up to 128 GB
Slots

CPU:
– 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*
Chipset:
– 2 x PCIe 3.0 x1 Slots (PCIE2 and PCIE3)*
– 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
Storage Interface

Chipset:
– 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode*
– 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) modes*
– 4 x SATA3 6.0 Gb/s Connectors
Onboard Graphics

2 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz
Audio

7.1 CH HD Audio (Realtek ALC897 Audio Codec)
USB

6 x USB 3.2 Gen1 Type-A (4 Rear, 2 Front)
6 x USB 2.0 (2 Rear, 4 Front)
Internal I/O Ports

1 x SPI TPM Header
1 x Chassis Intrusion and Speaker Header
1 x RGB LED Header*
3 x Addressable LED Headers**
1 x CPU Fan Connector (4-pin)***
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****
2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****
1 x 24 pin ATX Power Connector
1 x 8 pin 12V Power Connector
1 x Front Panel Audio Connector
2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
Back Panel Connectors

2 x Antenna Mounting Points
2 x HDMI Ports
4 x USB 3.2 Gen1 Type-A Ports
2 x USB 2.0 Ports
1 x RJ-45 LAN Port
HD Audio Jacks: Line in / Front Speaker / Microphone
I/O Controller

iTE I/O Controller Chip
BIOS

128Mb AMI UEFI Legal BIOS with GUI support
Operating System

Support for Windows 11 64-bit
Support for Windows 10 64-bit
Form Factor

9.6-in x 7.9-in, 24.4 cm x 20.1 cm
Warranty

1 Year
