Brand

Viewsonic

Model

IFP7534

Screen Size

75"

Panel Type

TFT LCD Module with DLED Backlight

Display Viewing Area (HxV)

1650.24(H) x 942.01(V)

Aspect Ratio

16:9

Resolution Type

UHD

Display Resolution

UHD 3840×2160 (Pixels)

Display Color

1.07B colors

Brightness

350 nits

Contrast Ratio

5000:1 (max. with DCR enabled)

Response Time

8ms

Viewing Angles

H = 178, V = 178

Backlight Life (Hours)

50,000 Hours (8 hours of use per day)

Surface Treatment

Hardness: 7H Anti-glare coating

Curvature

Flat

Orientation

Landscape

Processor

Quad-core

RAM

8GB DDR4

Storage

128 GB

Touch

Type/ Tech: Ultra Fine Touch Technology
Touch Resolution: 32767 x 32767
Touch Point: 40 points touch
Palm Rejection: Yes

Input

HDMI: x3 (Front x1: HDMI2.0/HDCP 2.2/CEC; Rear x 2:HDMI2.0/HDCP 2.2/CEC/ARC for HDMI 2)
RGB / VGA: x1
DisplayPort: x1
Audio: x1
RS232: x1
SD/SDHC: x1
OPS: x1 (Optional Intel Standard OPS)
WiFi: x1 (Optional VB-WIFI-004/VB-WIFI-006/VSB-050)

Output

HDMI: HDMI 2.0 x1
Audio: x1
SPDIF: x1

LAN

RJ45: x2

USB

Type A: USB3.2 Gen 1 x 4 (Front x 2; Rear x 2 )
USB 2.0×1 (Rear)
Type B: USB 3.0 x2 (Rear x1 + Front x1)
Type C: Front*1 [PD65W (15W with OPS, 65W without OPS)+ DP1.2 + Data + 10M/100M sharing)]
Rear *1 (PD15W +Data)

Speakers

16W x 2

Top Camera Plate

Yes

Embedded OS

Android 14 EDLA

Bundle Software

Basic Annotation Software: myViewBoard
Pro Annotation Software: myViewBoard for Windows (Embedded in optional Windows Slot-in PC)
Wireless Presentation: AirSync
Device Management: Manager
ViewSonic Launcher: Yes

Special Features

All-in-one USB port: (combine slot-in PC/Android/HDMI USB port) Front “SmartPort™ USB” to all channels.
Simple LAN sharing between IFP and slot-in device: 10/100M for Android & Slot-in PC
Light Sensor: Yes

Power

Voltage: 100-240V AC
Consumption: On:89.24W ; Off: ≤ 0.5W

Wall Mount

800 mm x 400 mm

Product Dimensions

Physical (inch / mm): 67.5 x 40.4 x 3.42 (in.) / 1716.5 x 1025.8 x 86.9 (mm)
Packaging (inch / mm): 73.22 x 44.29 x 7.28 (in.) / 1860 x 1125 x 185 (mm)

Weight

Net (lb / kg): 108.03 lb / 49 kg
Gross (lb / kg): 133.38 lb /60.5 kg

Regulations

FCC/ICES003, EPEAT, CE EMC, LVD or CB, RoHS Green BOM, & RoHS DoC, ErP, REACH SVHC List, & DoC, EEL, WEEE, BSMI,BIS

Energy Star version

8.0

EEI Rating

F

Color

Black

Warranty

1 Year

Compatible Slot-in PC

VPC3X, VPCF5-2A, VPCF5, VPC2X, VPC-A31-O1
